Electric forklift-CPD45-L
4500 kgRated Capacity
6630 kgSelf Weight
80/460 V/AhBattery Capacity
Electric forklift-CPD45-L

Electric forklift-CPD45-L

The 80 V dual-pump system offers higher power density and reduces energy consumption by 15% to 20% compared with conventional asynchronous-motor models under the same conditions. The ergonomic design and driver’s operating space are identical to those of an internal combustion forklift, effectively reducing driver fatigue. Thanks to the innovative layout, the bonnet and seat positions ensure a comfortable seating posture and ample legroom. A low center of gravity and generous load reserve improve truck stability for continuous material-handling operations. The complete truck has passed IPX4 rain testing and can continue operating normally during short periods of heavy rainfall.

Kontaktieren Sie unsModelle vergleichen
Position
Spezifikation
Einheit
  • Rated Capacity
    4500
    kg
  • Self Weight
    6630
    kg
  • Battery Capacity
    80/460
    V/Ah
  • Rated Load Center Distance
    500
    mm
  • Front Overhang
    555
    mm
  • Wheel Base
    2100
    mm
  • Tire Type
    Pneumatic
  • Mast Static Height
    2245
    mm
  • Free Lift Height
    150
    mm
  • Lift Height
    3000
    mm
  • Overall Length (Incl. Fork Vertical Face Length)
    3050
    mm
  • Overall Width
    1490
    mm
  • Fork Dimensions
    50/150/1070
    S/E/L mm
  • Min. Turning Radius
    2680
    mm
  • Max. Travel Speed (Full/Empty Load)
    19/19
    km/h
  • Max. Lifting Speed (Full/Empty Load)
    430/550
    mm/s
  • Lowering Speed (Full/Empty Load)
    370/420
    mm/s

Aufgrund kontinuierlicher technologischer Innovationen können sich Produktkonfigurationen und technische Parameter ohne vorherige Ankündigung ändern. Alle Spezifikationen und Konfigurationen dienen nur als Referenz. Bei Fragen wenden Sie sich bitte an unser internationales Vertriebsteam. Maßgeblich ist der formell unterzeichnete Geschäftsvertrag.

Produktübersicht

The 80 V dual-pump system offers higher power density and reduces energy consumption by 15% to 20% compared with conventional asynchronous-motor models under the same conditions. The ergonomic design and driver’s operating space are identical to those of an internal combustion forklift, effectively reducing driver fatigue. Thanks to the innovative layout, the bonnet and seat positions ensure a comfortable seating posture and ample legroom. A low center of gravity and generous load reserve improve truck stability for continuous material-handling operations. The complete truck has passed IPX4 rain testing and can continue operating normally during short periods of heavy rainfall.

  • The 80 V dual-pump system offers higher power density and reduces energy consumption by 15% to 20% compared with conventional asynchronous-motor models under the same conditions.

    The 80 V dual-pump system offers higher power density and reduces energy consumption by 15% to 20% compared with conventional asynchronous-motor models under the same conditions.

  • The ergonomic design and driver’s operating space are identical to those of an internal combustion forklift, effectively reducing driver fatigue. Thanks to the innovative layout, the bonnet and seat positions ensure a comfortable seating posture and ample legroom.

    The ergonomic design and driver’s operating space are identical to those of an internal combustion forklift, effectively reducing driver fatigue. Thanks to the innovative layout, the bonnet and seat positions ensure a comfortable seating posture and ample legroom.

  • A low center of gravity and generous load reserve improve truck stability for continuous material-handling operations.

    A low center of gravity and generous load reserve improve truck stability for continuous material-handling operations.

  • The complete truck has passed IPX4 rain testing and can continue operating normally during short periods of heavy rainfall.

    The complete truck has passed IPX4 rain testing and can continue operating normally during short periods of heavy rainfall.
